AZSB-GC Ceramic Head – Biomass Burning Automatic Set 100 kW

Products / AZSB-GC Ceramic Head – Biomass Automatic Set

AZSB is a modern device consisting of a heat exchanger, a feeding set, a burner and a fuel hopper.  The unique construction of the exchanger and a fuel automatic feeder makes an operation of AZSB unmanned, guarantees a high level of efficiency and low flue gas emission that conforms with EN 303-5 standard. Wide range of fuel hoppers (0,6;1;2; 6;8;10 m) allows the hopper to be filled in every 2-6 days, depending on fuel type and its caloric value. Fuel of 25% moisture content (briquette,tree bark,peat,shavings,woodchips,pellet,turf mole) can be well burnt in AZSB as well as  40%  moisture content woodchips,tree bark,peat,turf mole). It is possible due to the use of two types of a burner: ceramic and cast iron. When burning  fuel up to 40% moisture content  a ceramic burner is used (30, 50, 100, 240kW), when burning dry fuel (to max. 25% moisture content) a cast iron  burner is used (30, 60, 120, 240kW).

no-photo
woodchipspellets
  • Attestation
    UDT attestation, certificate of „ecology safety sign”
  • Equipment
    a controller, a blower, a thermometer, a cleaning set, a fuel bin , an ash box
  • Connection
    To a boiler options: a device from the right side/left side/ in front
  • Warranty
    24 months
  • AZSB- GC  (kW) 100
     Efficiency 84 %
     Water volume (l) 500
     Weight (kg) 1570
     Fuel tank capacity  (m3) 1-10
    Water working temperature (oC) 70-80
     Min. return water temperature (oC) 55
     Max. working pressure (bar) max. 1,5
     Flue dimensions (cmxcm) 25-25
     Chimney height (m) 8-10
     Min. chimney section (cm2/ø mm) 625/250
     Power supply 3˜ 400V

    When three-phased power is not available the APSB can run on a frequency converter.
