APSB-GZ Cast Iron Head – Biomass Burning Automatic Feeder 240 kW

Products / APSB-GZ Cast Iron – Biomass Automatic Feeder

APSB is a modern device designed for biomass burning in form of wooden shaving, woodchip,tree bark, briquette,turf mole,peat,cherry drupels and pellets. Moisture content in fuel determines a choice of a burner (ceramic or cast iron). Maximum content is 40%. APSB can be coupled with Moderator type boiler or any other type, which construction allows for it.  The burning process is controlled automatically. Application of  APSB is wide: from residential building, schools to industrial facilities. It was rewarded with the gold medal on Eco Woods Fair in 2001

woodchipspelletsbriquette
  • Equipment
    a controller, anti-fire set, a blower, rotary valve
  • Warranty
    24 months
    • APSB- GZ  (kW) 240
     Efficiency 84%
     Weight (kg) 820
     Fuel tank capacity  (m3) 6-10
     Power supply 3˜ 400V

    When three-phased power is not available the APSB can run on a frequency converter.
